Technical Article

Compare Patch levels across all installed sql instances

,

Ever wondered if all nodes are on the same patch (or version) level?

Is your failovers are taking longer than expected? Do you see tons of the lines in error logs saying upgrading or downgrading databases? Well, you can run SQL Server features discovery report on each server to compare sql versions or just run the script below.

Preliminary steps:

  1. Replace DECLARE @ServerNameList NVARCHAR(1000) = '"Server01","Server02","Server03"' with real server names.
  2. You need to be sysadmin on servers above.
  3. Run the script from any 1 sql instance installed on these servers.
  4. Use vertical or horizontal output, I couldn’t decide which one is better.

Sample output:

DECLARE @Value sql_variant
SELECT @Value = value_in_use FROM master.sys.configurations WHERE [name] = 'xp_cmdshell'

IF @Value = 0
BEGIN
EXEC sp_configure 'xp_cmdshell', 1
RECONFIGURE
END


DECLARE @ServerNameList NVARCHAR(1000) = '"Server01","Server02","Server03"'
DECLARE @PowerShellFile NVARCHAR(300) = 'C:TempGet-PatchLevel.ps1'  -- local folder on sql instance
DECLARE @PatchLevelFile NVARCHAR(100) = 'C:TempPatchLevel.txt'
DECLARE @OLE            INT
DECLARE @FileID         INT
DECLARE @Command        NVARCHAR(4000)
DECLARE @SQLServerRegistryKeyPath VARCHAR (256), @SQLVersion VARCHAR (56), @InstanceName VARCHAR (56), @SQLPath VARCHAR (356)
DECLARE @InstalledInstances  TABLE (InstanceName NVARCHAR(200))
DECLARE @Instances  TABLE (MachineName sysname, InstanceName NVARCHAR(200), [Version] NVARCHAR(50))


SET NOCOUNT ON;

IF EXISTS(SELECT 1 from tempdb.sys.objects WHERE [name] like '#FileContents%')
DROP TABLE #FileContents
CREATE TABLE #FileContents (Instance nvarchar(200), [Server] nvarchar(200), [Version] nvarchar(200))

EXEC ('xp_cmdshell ''del "' + @PatchLevelFile + '"'', no_output')

EXEC ('xp_cmdshell ''del "' + @PowerShellFile + '"'', no_output')

-- get all installed sql instances
SET @Command = 'powershell.exe "Get-Service | Where-Object {$_.Name -like ''MSSQL$*''}"'
INSERT INTO @InstalledInstances (InstanceName)
EXEC xp_cmdshell @Command

DELETE FROM @InstalledInstances WHERE InstanceName IS NULL OR CHARINDEX('SQL Server', InstanceName, 1) = 0

UPDATE @InstalledInstances
SET InstanceName = RTRIM(LTRIM(SUBSTRING(InstanceName, CHARINDEX('(', InstanceName, 1) + 1, LEN(InstanceName) - CHARINDEX('(', InstanceName, 1) - 1)))

DECLARE InstalledInstances CURSOR FOR
SELECT InstanceName FROM @InstalledInstances

OPEN InstalledInstances

FETCH NEXT FROM InstalledInstances INTO @InstanceName

WHILE @@FETCH_STATUS = 0
BEGIN
SET @SQLServerRegistryKeyPath = N'SoftwareMicrosoftMicrosoft SQL Server' + @InstanceName + 'Setup'
-- Get SQLPath for installed instance
EXEC [master]..[xp_regread]  N'HKEY_LOCAL_MACHINE'
,@SQLServerRegistryKeyPath
,'SQLPath'
,@SQLPath OUTPUT;

SET @SQLPath = RIGHT(@SQLPath, LEN(@SQLPath) - CHARINDEX('MSSQL', @SQLPath, 1) + 1)
SET @SQLPath = REPLACE(@SQLPath, 'MSSQL', '')
SET @SQLServerRegistryKeyPath = N'SoftwareMicrosoftMicrosoft SQL Server' + @SQLPath + 'Setup'
-- create PowerShell file
SET @Command = '
$ServerNameList = ' + @ServerNameList + '
#IF the output folder does not exist then create it
$OutputFolder = "c:Temp"
$DoesFolderExist = Test-Path $OutputFolder
$null = if (!$DoesFolderExist){MKDIR "$OutputFolder"}

foreach($ServerName in $ServerNameList)
{
$Reg = [Microsoft.Win32.RegistryKey]::OpenRemoteBaseKey(''LocalMachine'',$ServerName)
$RegKey = $Reg.OpenSubKey(''' + @SQLServerRegistryKeyPath + ''')
$Value = $RegKey.GetValue(''PatchLevel'')
''' + @InstanceName + ','' + $ServerName + '','' + $Value | out-file "' + @PatchLevelFile + '" -Append
}'
EXECUTE sp_OACreate 'Scripting.FileSystemObject', @OLE OUT
EXECUTE sp_OAMethod @OLE, 'OpenTextFile', @FileID OUT, @PowerShellFile, 8, 1

EXECUTE sp_OAMethod @FileID, 'WriteLine', Null, @Command

EXECUTE sp_OADestroy @FileID
EXECUTE sp_OADestroy @OLE

SET @Command = 'powershell.exe -ExecutionPolicy Bypass -File "' + @PowerShellFile + '"'

EXEC xp_cmdshell @Command, no_output
-- delete PowerShell file
EXEC ('xp_cmdshell ''del "' + @PowerShellFile + '"'', no_output')
FETCH NEXT FROM InstalledInstances INTO @InstanceName
END
CLOSE InstalledInstances;
DEALLOCATE InstalledInstances;

-- insert data from output PatchLevel file
BULK INSERT #FileContents
FROM 'c:tempPatchLevel.txt'
WITH
(DATAFILETYPE = 'widechar',
FIELDTERMINATOR = ',',
ROWTERMINATOR = 'n'
)

SELECT DISTINCT @Command = STUFF( ( SELECT  ',' + InstanceName + ''
FROM @InstalledInstances
ORDER BY InstanceName FOR XML PATH('') ), 1,1,'')

-- horizontal Pivot output
SET @Command = '
SELECT Server, ' + @Command + '
FROM
(SELECT [Instance], Server, Version
FROM #FileContents) p
PIVOT
(
MAX(Version)
FOR Instance IN
(' + @Command + ')
) AS pvt
ORDER BY pvt.Server'
EXEC(@Command)

-- vertical Pivot output
SET @Command = REPLACE(@ServerNameList, '"', '')
SET @Command = '
SELECT [Instance], ' + @Command + '
FROM
(SELECT [Instance], Server, Version
FROM #FileContents) p
PIVOT
(
MAX(Version)
FOR [Server] IN
(' + @Command + ')
) AS pvt
ORDER BY pvt.[Instance]'
EXEC(@Command)

-- Set it back
IF @Value = 0
BEGIN
EXEC sp_configure 'xp_cmdshell', 0
RECONFIGURE
END
GO
